Name: Geofabric V3x Major Rivers

Display Field: Name

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: <DIV STYLE="text-align:Left;font-size:12pt"><DIV><DIV><P><SPAN>Major Rivers selected from t</SPAN><SPAN>he </SPAN><SPAN>Bureau's </SPAN><SPAN>Australian Hydrological Geospatial Fabric (Geofabric) </SPAN><SPAN>V3x AHGFMappesStream dataset.</SPAN></P><P><SPAN>The AHGFMappedStreams are derived from the AusHydro V2 Watercourse feature class. The features have been organised into specific Feature Class subtypes based upon both the inputs from the AusHydro V2 Watercourse feature class and their behaviour within the AHGF stream network relationships</SPAN><SPAN>.</SPAN></P></DIV></DIV></DIV>

Service Item Id: bd9ddec5f5384138ad51c76284c3cdcc

Copyright Text: We request attribution as © Commonwealth of Australia (Bureau of Meteorology) 2020

Default Visibility: true

MaxRecordCount: 10000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 2000000

Max Scale: 0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: true

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 113.37527778100002
YMin: -43.62888887799994
XMax: 153.63166682400004
YMax: -10.060277569999926
Spatial Reference: 4283  (4283)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSLSSolid
Color: [0, 197, 255, 255]
Width: 1
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:
Label Placement: esriServerLinePlacementAboveAlong
Label Expression: N/A
Use Coded Values: true
Symbol:
Color: [0, 197, 255, 255]
Background Color: N/A
Outline Color: N/A
Vertical Alignment: bottom
Horizontal Alignment: left
Right to Left: false
Angle: 0
XOffset: 0
YOffset: 0
Size: 8
Font Family: Tahoma
Font Style: normal
Font Weight: bold
Font Decoration: none

Min. Scale: 500000.0
Max. Scale: 0.0

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: AHGFFType

Fields:

• hydroid ( type: esriFieldTypeInteger, alias: HydroID )
• ahgfftype ( type: esriFieldTypeInteger, alias: AHGFFeatureType , Coded Values: [1: NetworkFlowSegment] , [2: NetworkArtificialFlowSegment] , [3: NetworkWaterAreaSegment] )
• name ( type: esriFieldTypeString, alias: Name, length: 60 )
• hierarchy ( type: esriFieldTypeString, alias: Hierarchy, length: 14 , Coded Values: [Major: Major] , [Minor: Minor] , [Not Applicable: Not Applicable] )
• perennial ( type: esriFieldTypeString, alias: Perenniality, length: 14 , Coded Values: [Perennial: Perennial] , [Non Perennial: Non Perennial] , [Not Applicable: Not Applicable] )
• geodeslen ( type: esriFieldTypeDouble, alias: GeodesicLength m )
• upstrgeoln ( type: esriFieldTypeDouble, alias: UpstreamGeodesicLength m )
• from_node ( type: esriFieldTypeInteger, alias: From_Node )
• to_node ( type: esriFieldTypeInteger, alias: To_Node )
• nextdownid ( type: esriFieldTypeInteger, alias: NextDownID )
• flowdir ( type: esriFieldTypeInteger, alias: FlowDir , Coded Values: [0: Uninitialized] , [1: WithDigitized] , [2: AgainstDigitized] , ...1 more... )
• srcfcname ( type: esriFieldTypeString, alias: SourceFeatureClassName, length: 25 )
• srcftype ( type: esriFieldTypeString, alias: SourceFeatureType, length: 32 )
• srctype ( type: esriFieldTypeInteger, alias: SourceType )
• sourceid ( type: esriFieldTypeInteger, alias: SourceID )
• aushydroid ( type: esriFieldTypeInteger, alias: AusHydroID )
• featrel ( type: esriFieldTypeDate, alias: FeatureReliability, length: 8 )
• fsource ( type: esriFieldTypeString, alias: FeatureSource, length: 25 )
• attrrel ( type: esriFieldTypeDate, alias: AttributeReliability, length: 8 )
• attrsource ( type: esriFieldTypeString, alias: AttributeSource, length: 25 )
• planacc ( type: esriFieldTypeSmallInteger, alias: PlanimetricAccuracy )
• textnote ( type: esriFieldTypeString, alias: TextNote, length: 50 )
• st_length(shape) ( type: esriFieldTypeDouble, alias: st_length(shape) )
• objectid ( type: esriFieldTypeOID, alias: OBJECTID )
• enabled ( type: esriFieldTypeSmallInteger, alias: Enabled , Coded Values: [0: False] , [1: True] )
• symbol ( type: esriFieldTypeSmallInteger, alias: Symbol )
• shape ( type: esriFieldTypeGeometry, alias: Shape )
• aushydroer ( type: esriFieldTypeSmallInteger, alias: AusHydroIDError )
• segmentno ( type: esriFieldTypeInteger, alias: SegmentNo )
• drainid ( type: esriFieldTypeInteger, alias: DrainID )
• upstrdarea ( type: esriFieldTypeDouble, alias: UpstreamDrainageArea )
• concatid ( type: esriFieldTypeInteger, alias: ContractedCatchmentID )
• stroutlet ( type: esriFieldTypeInteger, alias: StreamOutlet )

Types:

ID: 3
Name: NetworkWaterAreaSegment
Domains:
• ahgfftype:
  Inherited
• hierarchy:
  Inherited
• perennial:
  Inherited
• enabled:
  Inherited
• flowdir:
  Inherited

---

ID: 2
Name: NetworkArtificialFlowSegment
Domains:
• ahgfftype:
  Inherited
• hierarchy:
  Inherited
• perennial:
  Inherited
• enabled:
  Inherited
• flowdir:
  Inherited

---

ID: 1
Name: NetworkFlowSegment
Domains:
• ahgfftype:
  Inherited
• hierarchy:
  Inherited
• perennial:
  Inherited
• enabled:
  Inherited
• flowdir:
  Inherited

---

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
